| Carbon | Alloy | Dimension (mm) | Weight (kg/pc) |
||||||
|---|---|---|---|---|---|---|---|---|---|
| WLL/T | B.L./T | WLL/T | B.L./T | Φ | E | H | K | L | |
| 0.5 | 2.5 | 0.75 | 3.75 | 16.5 | 19 | 17 | 72 | 97 | 0.21 |
| 0.75 | 3.75 | 1 | 5 | 19 | 22 | 19 | 82 | 110 | 0.28 |
| 1 | 5 | 1.5 | 7.5 | 23 | 23 | 21 | 93.5 | 125 | 0.4 |
| 1.5 | 7.5 | 2 | 10 | 28 | 24 | 26 | 103 | 140.5 | 0.65 |
| 2 | 10 | 3 | 15 | 31 | 27.5 | 28 | 119 | 162 | 0.95 |
| 3 | 15 | 5 | 25 | 39 | 33 | 37 | 146 | 201 | 1.95 |
| 5 | 25 | 7 | 35 | 51 | 40 | 46.5 | 186.5 | 256 | 3.77 |
| 7.5 | 37.5 | 11 | 55 | 62 | 51 | 57 | 231.5 | 317 | 6.8 |
| 10 | 50 | 15 | 75 | 73 | 57 | 67 | 261 | 360 | 9.8 |
| 15 | 75 | 22 | 110 | 89 | 75 | 76 | 318 | 434 | 16.25 |
| 20 | 100 | 30 | 135 | 90 | 82 | 91 | 360 | 495.5 | 27.2 |
