| Size | W.L.L. (t) |
B.L (t) |
Dimension (mm) | Weight (kg/pc) |
||||
|---|---|---|---|---|---|---|---|---|
| E | B | H | Φ | R | ||||
| 6-8 | 1.12 | 4.48 | 29 | 8.5 | 19.5 | 34 | 95.5 | 0.5 |
| 7/8-8 | 2 | 8 | 34 | 9.5 | 24 | 46 | 121 | 0.8 |
| 10-8 | 3.15 | 12.8 | 44 | 12 | 28.5 | 56 | 146 | 1.5 |
| 13-8 | 5.3 | 21.2 | 52 | 15 | 40 | 69 | 182 | 2.8 |
| 16-8 | 8 | 32 | 60 | 18 | 50.5 | 86 | 218 | 5.6 |
| 20-8 | 12.5 | 50 | 83 | 25 | 55 | 100 | 240 | 7.5 |
| 22-8 | 15 | 60 | 88 | 25.5 | 67 | 98 | 276.5 | 11.5 |
| 26-8 | 21.2 | 84.8 | 95.5 | 30 | 75 | 110 | 310.5 | 18.5 |
